ISOX – 600 ohm 1:1 Isolation Transformer

The ISOX is a 1:1 600-ohm transformer designed to reduce hum and noise on an audio input. It provides the necessary isolation for a clean signal. The connection on both sides
of the ISOX are 3-pin screw down terminals. The back side of the ISOX is covered with Velcro fasteners, so it can be easily mounted wherever it is convenient.

Specifications
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 2.5” X 1.3” X .6”
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0 oz.
Frequency Response . . . . . . . . . . . . . . . . . 200Hz to 20kHz
Distortion (0dB/at1.0kHz) . . . . . . . . . . . . . . . . . . . . . . .005%
